If you want to input penalty points as well change with cursor key the pointer to the penalty
points (left field of display 8).
Press handswitch (channel 9) when the obstacle is set up.
The time in display (7) must run.
Penalty time from time violation (stage 2):
The penalty time from the time violation will be automatically calculated, if you input the maximum
allowed time (menu 38, parcour time). If you have also a penalty time from obstacle set up, then this
time will be added when pressing the <F3> key after the rider finish.
Recalculation of the Total Time (stage 2):
The penalty seconds for obstacle set are added immediately to the run time. Penalty seconds for
obstacle drop and time violation are added after the rider finish. When you press the <F3> key it
adds all up and prints the total time.
Function of the keyboard:
clear Start Time
recall last Start Time that was cleared ALT + CLEAR
clear Finish Time
recall last Finish Time that was cleared
block Start Time
Ignore Start Time
block Finish Time
ignore Finish Time
manipulate Start Time
manipulate Finish Time
manipulate Penalty Points
manipulate Penalty Time
Timing Channels: c0
c1
Time-out
ALGE adjustments for the main menu:
Menu 1:
Delay Time Start
Menu 2:
Delay Time Finish
Menu 3:
Seconds Mode
Menu 4:
Display Time 1
Menu 9:
Running Tenth
Menu 11: Finish Rank
Menu 15: Print Menus
Menu 16: Printer Linefeed
Menu 17: RS-232 Baudrate
Menu 18: RS-232 Run Time
Menu 19: D-Board Baudrate
Menu 20: D-Board Channel 2 = standing
Version:E-00-08-08
TdC 8000 for Equestrian
Keyboard 9 and 14
CLEAR
BLOCK
ALT + BLOCK
INPUT
=
Start Channel
= Finish Channel
= 1.0 s
= 0.3 s
= off
= 03 sec.
= off
= on
= on
= 0
= 9600 Baud
= off
= 2400 Baud
Keyboard 15 and 14
CLEAR
ALT + CLEAR
BLOCK
ALT + BLOCK
INPUT
Points, than INPUT
Time, than INPUT
c2 to c8 .... no function
c9
=
Menu 21: Beep
Menu 25: Change Race
Menu 26: D-Board-Test
Menu 36: Penalty Points 1
Menu 37: Time Violation 1
Menu 38: Time Violation 2
Menu 39: Parcour Time 1
Menu 40: Parcour Time 2
Menu 41: Block Time 1
Menu 42: Block Time 2
Menu 43: Count Down Time 1 = 000060.00
Menu 44: Count Down Time 2 = 000030.00
Menu 45: D-Board Count Down = on
Page 88
Countdown and
= on
= off
= 04.00
= 00.25
= 01.00
= 000.00
= 000.00
= 000.00
= 000.00
