RS 232 Run Time:
The RS 232 interface (23) outputs always in the difference-timing mode the time of day. Additional
you can output the run time.
output time of day and run time = <F1>
output time of day = <F2>
Menu 18: RS-232 RUN TIME
Save with: ENTER
Pre adjusted value:RS-232 Runtime = off
Display Board Baudrate:
You can adjust the baud rate for the display board (24, 28): 2400, 4800, 9600, or 19200 baud.
When using the ALGE display board you must use 2400 baud.
Menu 19: D-BOARD BAUDRATE
Save with: ENTER
Pre adjusted value:D-Board Baudrate = 2400 Baud
Display Board Channel 2:
You can adjust the channel 2 of the display board interface (24). If you have channel two on
STANDING, it outputs no running time (only run times). It outputs the classement always on chan-
nel 2. You can select between channel 1 and channel 2 by turning the plug of the display board
cable 180°.
Menu 20: D-BOARD CHANNEL 2
Save with: ENTER
RUNNING = <F1>
STANDING = <F2>
Pre adjusted value:
Beep:
The beep makes a sound for each timing impulse. The length of the beep depends on the adjusted
delay time. If the beep bothers people in the timing shack it is possible to turn it off. The beep goes
automatically on, as soon as you turn the TdC 8000 on.
Menu 21: BEEP
Save with: ENTER
Pre adjusted value:Beep is on
Version: E-01-08-08
TdC 8000 for Equestrian
Menu 18: RS-232 RUN TIME = OFF
Confirm selection with <ENTER>
Menu 19: D-Board Baudrate = 2400 Bd
Menu 20: D-BOARD CHANNEL 2 = OFF
running time and classement
run time and classement
D-Board Channel 2 is running time
Menu 21: BEEP = ON
output run time and
ON F1
output time of day
OFF< F2
Select with <F1>
2400 Bd F1
Select with <F2>
4800 Bd F2
Select with <F3>
9600 Bd F3
Confirm selection with
19200 Bd F4
<ENTER>
output of running time
RUNNING F1
output of run times
STANDING< F2
Confirm selection with
<ENTER>
Beep is on
ON F1
Beep is off
OFF< F2
Page 35
