ALGE-Timing TdC 8000 Manual page 11

Attention: Please take care that the paper goes through the paper slotted hole of the cover when
you put the cover back on.
Clearing Jammed Paper:
Press the black lever forward and pull back the remaining paper.
Remove the serrated cutter by holding the black lever forward and sliding the cutter towards
the
lever and lifting upwards.
Pull the print head back with your fingernail and remove any stuck paper with tweezers or
small
needlenose pliers.
If the paper has jammed under the roller it will be necessary to remove it by sliding a piece of
35 mm film through the paper path and rocking it to and fro until the stuck paper is expelled.
Use a piece of film about 20 cm long to have something to hold onto.
The printer is a very rugged device but needs regular maintenance for a long service life. Call your
ALGE agent if you have further questions.
Printer-Paper:
Electrosensitive paper 60 mm width, 40 mm diameter with about 25 m paper length (about 6000
lines). The electrosensitive paper is available at your ALGE representative.
A black strip will become visible on the edge of paper, when a paper roll is about to run out.
Attention: Do not pull on the paper when printing. Press the black lever forward and pull the
paper
carefully out, if the paper is repressed. The printer-paper has to stay dry!
Version: E-01-08-08
TdC 8000 for Equestrian
Insert the beginning of the paper into the paper feed of
the printer. Make sure it is cleanly out.
If necessary correct the paper path through pressing
the black lever forward and adjusting the paper
manually.
Put the cover back and press the button until they stay
in the lower position.
