ALGE-Timing TdC 8000 Manual page 45

- Correction of total penalty points (obstacle drop) by input of total amount and pressing
<INPUT> (keyboard 15)
- Time-out for set up of obstacle by pressing handswitch (channel 9). It stops the running time.
When the time is stopped it is possible to input a penalty time (display 8, right number). The
penalty time must be confirmed with <ENTER> (keyboard 15). It is possible to switch
between penalty seconds and penalty points with the cursor keys.
- When a rider reaches the finish it stops the run time. The penalty points from time violation
are calculated automatically.
- Press key <F3> to calculate the total penalty points and total run time.
- Input start number for the next competitor with keyboard (9), e.g. start number 2
- Confirm with <ENTER> (keyboard 9)
- etc.
Adjustments that you have to make before the race starts:
Before you start a race you have to check and maybe change some adjustments at the TdC 8000.
Press <ALT> and <MENU> at the same time to open the main menu. If can get direct into the
needed sub menu by input of the menu number with keyboard (15) and confirm it with <ENTER>.
Penalty Points: Menu 36
The standard penalty points for obstacle drop you can adjust in this menu. You can set the penalty
points from 0.01 to 99.99. Normally there is a 4 point penalty for obstacle drop.
Menu 36: PENALTY POINTS = 04.00
Save with: ENTER
Pre adjusted value:
Time Violation 1:
You can adjust the penalty points for time violation. The adjustment is between 0.00 and 99.99
possible. The penalty points are added for each started second time violation. Normally it is a 0.25
time violation for standard show jumping.
Menu 37: TIME VIOLATION 1 = 00.25
Save with: ENTER
Pre adjusted value:
Version: E-01-08-08
TdC 8000 for Equestrian
Penalty Points = 04.00
4 points
Menu 37 Time Violation 1 = 0,25
0,25 pointsParcour Time 1:
Adjusted penalty points
Save and exit with <ENTER>
Adjusted time penalty
Save and exit with <ENTER>
