4.2.3.

Individual adjustment of the channels

You can adjust each channel individual. When you turn the TdC 8000 on and clear the memory you
have always all channels active.
- If you press <MENU> and <BLOCK> together it shows the setting of each channel in the info-
display (6).
- Select the channel with ¢ and £ .
- Press <F1> to switch between activated and deactivated
- A (+) means, that the channel is activated.
- A (-) means, that the channel is deactivated.
- Leave the menu by pressing <MENU> and <BLOCK> together.
Info-display (6):
Channels on (+)/off (-):
+ + +
c0 c1 c2 c3 c4 c5 c6 c7 c8 c9
The adjustment above comes automatically when you turn the device after you cleared the memory:
The example bellow shows that channel c3 and c4 is switched off:
Channels on (+)/off (-):
+ + +
c0 c1 c2 c3 c4 c5 c6 c7 c8 c9
Version:E-00-08-08
TdC 8000 for Equestrian
+ + + + + +
- - + + + +
CHANGE F1
+
CHANGE F1
+
