Two Stage Show Jumping: Program 121 - ALGE-Timing TdC 8000 Manual

6.1.10. Two Stage Show Jumping:
1
Start Stage 1
Program with two stages. All competitors ride the first stage. Whoever passes the first stage without
penalty points will be allowed for the second stage. If a rider has penalty points in the first stage he
will not be allowed for the second stage.
Standard penalty points per started second time violence:
Stage 1: ¼ penalty point per started second time violence
Stage 2: 1 penalty point per started second time violence
Adjustment:
- Switch TdC 8000 on (switch 26)
- Select program 11 "Show Jumping" with cursor key (¢ and £)
- Press <ENTER>
- Select program 121 "Two Stage Jumping" with cursor key (¢ and £)
- Press <ENTER>
- Select race that you want to use and clear memory (e.g. <F1> for race 1)
- Press <ENTER>
- Select race (e.g. <F1> for race 1)
- Press <ENTER>
- Select the precision with key <F1> to <F4>. Standard is <F3> with 1/100 seconds
- Press <ENTER>
- Select the timing mode (we recommend <F2> for Difference Timing")
- Press <ENTER>
- Synchronize the TdC 8000 (with time of day and other timing devices)
- press <F1> if the finish display (7) shows the correct time of day
- wait until TdC 8000 gives at the next full minute the synchronize signal to external devices
(you are now ready for timing)
- press <F2> if the finish display (7) shows the wrong time of day
- input the time of day, confirm it with <ENTER> and make a start signal (channel 0 or
press <START>
- Press <ALT> and <MENU> together.
- Adjust menu 36, 37, 39, 41, 42, 43 and 45 as required by the circumstances of your event
(see next page).
- Exit the menu when you did all adjustments with <NO>.
Version:E-00-08-08
TdC 8000 for Equestrian
2 3 4 5 6 7
Obstacles
Finish Stage 1
as well as
Start Start Stage 2
1 2 3 4
Obstacles
Finsh Stage 2
Page 64
Program 121
Page 64
