Parameter List; Actual Values - BONFIGLIOLI Vectron Agile Series Communications Manual

Parameter List

17 Parameter List
The parameter list is structured according to the menu branches of the Operator Panel. For better
clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets
The parameter value is set by the SET-UP routine
This parameter cannot be written when the frequency inverter is in operation
17.1

Actual Values

No.
228 Internal Reference Frequency
249 Active Data Set
250 Digital Inputs
260 Actual Error
270 Warnings
274 Application Warnings
281 DP-Master OUT
282 Reference bus frequency
283 Reference ramp frequency
284 DP-Master IN
365 Status Control
366 Status Fieldbus Module
411 Status Word
Note: The Parameters
the VPlus PC-Software.
The Parameters
only accessible via the communication channel of objects PPO1, PPO2 and DP-V1. They
cannot be accessed via the VPlus PC-Software or the Operator Panel.
06/2010
Actual Values of the Frequency Inverter
Description
DP Master OUT
Actual Error
Profibus DP V1 Agile
Units Display Range
Hz -1000,00 ... 1000,00
- 1 ... 4
- 0 ... 255
- 0 ... 0xFFFF
- 0 ... 0xFFFF
- 0 ... 0xFFFF
- String
Hz -1000,00 ... 1000,00
Hz -1000,00 ... 1000,00
- String
- 0 ... 7
- 1 ... 15
- 0 ... 0xFFFF
DP Master IN
281 and
Warnings
270, 270 and
Chapter
16.4.5
16.4.1
16.4.4
18.2
18.1
18.2
16.5
16.4.5
16.4.5
16.5
11
11
16.4.1
284 can only be displayed via
Application Warnings
274 are
57
