Handling of the Objects
16.4.3.1 State machine diagram
The device control commands are triggered by the following bit pattern in the Control Word:
Command
Shutdown
Switch On
Switch On
Disable Voltage
06/2010
Control Word
Bit 7 Bit 3
Reset Fault Enable Quick
Operation Stop
X X
X 0
X 1
X X
Profibus DP V1 Agile
Bit 2 Bit 1 Bit 0
Enable Switch
Voltage On
1 1 0
1 1 1
1 1 1
X 0 X
Transitions
2, 6, 8
3
3
7, 9, 10, 12
