Example 2
Parameter 480 is a double word (P[I]-D), long, data set change-over capable, and is to be written.
The target data set is data set 3.
Reference value = -300.00 Hz (-30000 is transmitted)
The negative value is portrayed as follows in accordance with integer arithmetic: 0xFFFF8AD0
Request from Master:
AK = 8 (request identification = write parameter value long Array)
PNU = 480 (= 0x1E0)
IND = 3
PWEh = 0xFFFF
PWEl = 0x8AD0
Designation
Content
Byte No.
Reply from Slave:
AK = 5 (reply identification = transmit parameter value long Array)
PNU = 480 (= 0x1E0)
IND = 3
PWEh = 0xFFFF
PWEl = 0x8AD0
Designation
Content
Byte No.
30
PKE
Parameter Index
Identification
High Low High
Byte Byte Byte
0x81 0xE0 3
0 1 2
PKE
Parameter Index
Identification
High Low High
Byte Byte Byte
0x51 0xE0 3
0 1 2
Profibus DP V1 Agile
PKW area
IND PWE high
Parameter value
High Word
Low High
Byte Byte
0 0xFF
3 4
PKW area
IND PWE high
Parameter value
High Word
Low High
Byte Byte
0 0xFF
3 4
Handling of the Objects
PWE low
Parameter value
Low Word
Low High Low
Byte Byte Byte
0xFF 0x8A 0xD0
5 6 7
PWE low
Parameter value
Low Word
Low High Low
Byte Byte Byte
0xFF 0x8A 0xD0
5 6 7
