Profibus

7 Profibus
This document describes the possibilities and characteristics of the Profibus DP communication module
CM-PDPV1 for the device series Agile.
For the Profibus-DP connection, the frequency inverter must be equipped with the Profibus-DP
communication module CM-PDPV1. The Profibus component CM-PDPV1 is enclosed with the inverter
as a separate part and must be fitted by the user.
Note: These instructions are not to be understood as fundamental information on Profibus-DP.
They presuppose underlying knowledge of the methods and modes of effect of Profibus-
DP on the part of the user.
In some sections, setting and display possibilities are described, alternatively to the
Operator Panel, via the VPlus PC-Software. Operation of a PC with the VPlus PC-Software
on the frequency inverter with use of the Profibus component CM-PDPV1 is only possible
via an optional interface adapter.
The Profibus component CM-PDPV1 has the ident number 0x0B2C (hexadecimal). The device's
data set file has the designation BV__0B2C.GSD. The identification number and designation of the
GSD file were assigned by the Profibus User Organization in Karlsruhe, Germany.
Attention! With the help of the Profibus-DP communication module CM-PDPV1 it is possible to
access ALL parameters of the frequency inverter from the external control unit. Control
of the access via the Control Level (Parameter 28) as with the Operator Panel or the
VPlus PC-Software does not exist. A change of parameters with an unknown meaning to
user can lead to the inoperability of the frequency inverter.
