Note: The displayed "PDP active current" depends on the control system. In field-orientation,
the torque-forming current is displayed, in applications with a v/f characteristic control,
the active current, which is also a measure for the torque.
The "PDP absolute current" (r.m.s. current) is always positive. Active current and torque-
forming current have a sign prefixed.
Positive currents = motor
Negative currents = generator operation.
Current Scaling
Reference value
+ 100%
The possible range = ±200% = +32768 to -32768 = 0x8000 to 0x7FFF
For the internal scaling, the data set change-over capable parameter
reference.
Parameter
No.
371 Rated Current
38
Standardization
Binary Decimal
14
+ 2 16384
Description
Profibus DP V1 Agile
Hexadecimal
0x4000
Setting
Min. Max.
0,01 · I 10 · I
FUN FUN
Handling of the Objects
Rated current
371 is used as a
Factory Setting
I
FUN
