Parameter List; Actual Value Menu (Val); Parameter Menu (Para) - BONFIGLIOLI ACTIVE Applications Manual

6
The parameter list is structured according to the menu branches of the operating unit.
For better clarity, the parameters have been marked with pictograms:
6.1
6.2
26
26

Parameter list

The parameter is available in the four data sets
The parameter value is set by the SET-UP routine
This parameter cannot be written in the operation of the frequency inverter.

Actual value menu (VAL)

Actual values of the system
No. Description
242 Load
243 Estimated load

Parameter menu (PARA)

Temperature adjustment
No. Description
465 Operation mode
467 Adjusting temperature
769 Frequency Upper Limit Source
800 Time t1
801 Time t2
802 Time t3
803 Time t4
804 Time t11
805 Time t12
806 Time t13
807 Time t15
808 Monitoring current
809 Frequency threshold
811 Mech. time constant
812 Turn/m
813 Fm lower value LE
815 Max time LE
816Pull-out torque at Fmax
817Speed switch-off Limit
818I limit
819Desired Isq up
820 Desired Isq down at FsR
821 Desired Isq down at Fmax
822 Operation mode LE
Unit
%
%
Unit
-
°C
Speed controller
-
Brake control
s
s
s
s
s
s
s
s
A
%
Load estimation
s
U/m
%
s
%
Hz
A
A
A
A
-
Display range Chapter
0.0 ... 999.9
0.0 ... 999.9
Display range Chapter
Selection
-50.0 ... 300.0
Selection
0.0 ... 20.0
0.0 ... 20.0
0.0 ... 20.0
0.0 ... 20.0
0.0 ... 20.0
0.0 ... 20.0
0.0 ... 20.0
0.0 ... 20.0
0.0 ... o⋅I
FIN
0.0 ... 100.0
0.000 ... 65.000
0.01 ... 650.00
0 ... 100
0.001 ... 65.000
0 ... 100
0.00 ... 999.99
0.01⋅I ... 3⋅o⋅I
FIN FIN
0.01⋅I ... o⋅I
FIN FIN
0.01⋅I ... o⋅I
FIN FIN
0.01⋅I ... o⋅I
FIN FIN
Selection
5.1
5.1
5.4
5.4
5.3
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2.1
4.2.2
5.1.1
5.1.2
5.1.3
5.1.3
5.1.3
5.1.3
5.1.3
5.2.1
5.2.1
5.2.1
5.1
