Annex

18 Annex
18.1

Warning Messages

The various control functions and methods and the hardware of the frequency inverter contain
functions that continuously monitor the application. In addition to the messages documented in the
manual, the following warning messages are activated by the Profibus-DP communication module
CM-PDPV1.
The warning messages are given via parameter
scheme.
Warnings
Parameter
software tool VPlus.
Warnings
Use Parameter
Bit-No. Warning
Code
0 0x0001
1 0x0002
2 0x0004
3 0x0008
4 0x0010
5 0x0020
6 0x0040
7 0x0080
8 0x0100
9 0x0200
10 0x0400
11 0x0800
12 0x1000
13 0x2000
14 0x4000
15 0x8000
Note: The meaning of the individual warnings are described in detail in the operating
instructions.
06/2010
269 shows the warnings in clear text on the operator panel and the PC
270 to access the warning codes via Profibus.
Warning Messages
Warning Ixt
Warning Short Term - Ixt
Warning Long Term - Ixt
Warning Heat Sink Temperature Tk
Warning Inside Temperature
Warning Limit
Warning Init
Warning Motor Temperature
Warning Mains Failure
Warning Motor Protective Switch
Warning Fmax
Warning Analog Input MFI1A
Warning Analog Input MFI2A
Warning Systembus
Warning Udc
Warning Application
Profibus DP V1 Agile
Warnings
270, bit-coded according to the following
Description
