MVI56-PNPM Status Data Definition

This section contains a description of the members present in the PNPInStat
object. This data is transferred from the module to the processor as part of each
read block.
Offset Content
202 Program Scan
Count
203 to 204 Product Code
205 to 206 Product Version
207 to 208 Operating System
209 to 210 Run Number
211 Port 1 Command
List Requests
212 Port 1 Command
List Response
213 Port 1 Command
List Errors
214 Port 1 Requests
215 Port 1 Responses
216 Port 1 Errors Sent
217 Port 1 Errors
Received
218 Port 2 Command
List Requests
219 Port 2 Command
List Response
220 Port 2 Command
List Errors
221 Port 2 Requests
222 Port 2 Responses
223 Port 2 Errors Sent
224 Port 2 Errors
Received
225 Read Block Count
226 Write Block Count
ProSoft Technology, Inc.
January 2, 2008
MVI56-PNPM ♦ ControlLogix Platform
Phantom Network Protocol Master Communication Module
Description
This value is incremented each time a complete program
cycle occurs in the module.
These two registers contain the product code of "PNP".
These two registers contain the product version for the
current running software.
These two registers contain the month and year values for
the program operating system.
These two registers contain the run number value for the
currently running software.
This field contains the number of requests made from this
port to slave devices on the network.
This field contains the number of slave response messages
received on the port.
This field contains the number of command errors processed
on the port. These errors could be due to a bad response or
command.
This field contains the total number of messages sent out of
the port.
This field contains the total number of messages received on
the port.
This field contains the total number of message errors sent
out of the port.
This field contains the total number of message errors
received on the port.
This field contains the number of requests made from this
port to slave devices on the network.
This field contains the number of slave response messages
received on the port.
This field contains the number of command errors processed
on the port. These errors could be due to a bad response or
command.
This field contains the total number of messages sent out the
port.
This field contains the total number of messages received on
the port.
This field contains the total number of message errors sent
out the port.
This field contains the total number of message errors
received on the port.
This field contains the total number of read blocks transferred
from the module to the processor.
This field contains the total number of write blocks
transferred from the module to the processor.
