Write Configuration
This block is sent from the ControlLogix processor to the module to force the
module to write its current configuration back to the processor. This function is
used when the module's configuration has been altered remotely using database
write operations. The write block contains a value of -9000 in the first word. The
module will respond with blocks containing the module configuration data. Ladder
logic must handle the receipt of these blocks. The blocks transferred from the
module are as follows:
Block -9000, General Configuration Data:
Offset
0
1
2 to 7
8 to 21
22 to 35
36 to 248
Blocks -6000 to -6003 and -6100 to -6103, Master Command List Data for ports 1
and 2, respectively:
Offset
0
1
2 to 9
10 to 17
18 to 25
26 to 33
34 to 41
42 to 49
50 to 57
58 to 65
66 to 73
74 to 81
82 to 89
90 to 97
98 to 105
106 to 113
114 to 121
122 to 129
130 to 137
138 to 145
146 to 153
154 to 161
162 to 169
Page 60 of 91
Description
Reserved
-9000
Backplane Setup
Port 1 Configuration
Port 2 Configuration
Spare
Description
Reserved
-6000 to -6003 and -6100 to -6103
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Command Definition
Reference
Length
1
1
6
14
14
213
Length
1
1
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
