Diagnostics and Troubleshooting
A simple communication program called HyperTerminal is pre-installed with
recent versions of Microsoft Windows operating systems. If you are connecting
from a machine running DOS, you must obtain and install a compatible
communication program. The following table lists communication programs that
have been tested by ProSoft Technology.
DOS
Windows 3.1
Windows 95/98
Windows NT/2000/XP

4.1.4 Using the Configuration/Debug Port

To connect to the module's Configuration/Debug port:
Connect your computer to the module's port using a null modem cable.
1
Start the communication program on your computer and configure the
2
communication parameters with the following settings:
Baud Rate
Parity
Data Bits
Stop Bits
Software Handshaking
Open the connection. When you are connected, press the [?] key on your
3
keyboard. If the system is set up properly, you will see a menu with the
module name followed by a list of letters and the commands associated with
them.
If there is no response from the module, follow these steps:
Verify that the null modem cable is connected properly between your
1
computer's serial port and the module. A regular serial cable will not work.
Verify that RSLinx is not controlling the COM port. Refer to Disabling the
2
RSLinx Driver for the Com Port on the PC (page 65).
Verify that your communication software is using the correct settings for baud
3
rate, parity and handshaking.
On computers with more than one serial port, verify that your communication
4
program is connected to the same port that is connected to the module.
If you are still not able to establish a connection, you can contact ProSoft
Technology Technical Support for further assistance.
ProSoft Technology, Inc.
January 2, 2008
Phantom Network Protocol Master Communication Module
ProComm, as well as several other terminal emulation programs
Terminal
HyperTerminal
HyperTerminal
57,600
None
8
1
None
MVI56-PNPM ♦ ControlLogix Platform
Page 33 of 91
