ProSoft Technology MVI56-PNPM User Manual page 61

Reference
Offset
170 to 177
178 to 185
186 to 193
194 to 201
202 to 248
249
Each of these blocks must be handled by the ladder logic for proper module
operation.
Warm Boot
This block is sent from the ControlLogix processor to the module (output image)
when the module is required to perform a warm-boot (software reset) operation.
This block is commonly sent to the module any time configuration data
modifications are made in the controller tags data area. This will force the module
to read the new configuration information and to restart. The structure of the
control block is shown in the following table:
Offset
0
1 to 247
Cold Boot
This block is sent from the ControlLogix processor to the module (output image)
when the module is required to perform the cold boot (hardware reset) operation.
This block is sent to the module when a hardware problem is detected by the
ladder logic that requires a hardware reset. The structure of the control block is
shown in the following table:
Offset
0
1 to 247
ProSoft Technology, Inc.
January 2, 2008
Phantom Network Protocol Master Communication Module
Description
Command Definition
Command Definition
Command Definition
Command Definition
Spare
-6000 to -6003 and -6100 to -6103
Description
9998
Spare
Description
9999
Spare
MVI56-PNPM ♦ ControlLogix Platform
Length
8
8
8
8
47
1
Length
1
247
Length
1
247
Page 61 of 91
