Start Here

1 Start Here
In This Chapter
Installing the MVI56-PNPM module requires a reasonable working knowledge of
the Rockwell Automation hardware, the MVI56-PNPM Module and the
application in which they will be used.
Caution: It is important that those responsible for implementation can complete
the application without exposing personnel, or equipment, to unsafe or inappropriate
working conditions. Safety, quality and experience are key factors in a successful
installation.
1.1

System Requirements

The MVI56-PNPM module requires the following minimum hardware and
software components:
Rockwell Automation ControlLogix™ processor, with compatible power
supply and one free slot in the rack, for the MVI56-PNPM module. The
module requires 800mA of available power.
Rockwell Automation RSLogix 5000 programming software version 2.51 or
higher.
Rockwell Automation RSLinx communication software
Pentium® II 450 MHz minimum. Pentium III 733 MHz (or better)
recommended
Supported operating systems:
o Microsoft Windows XP Professional with Service Pack 1 or 2
o Microsoft Windows 2000 Professional with Service Pack 1, 2, or 3
o Microsoft Windows Server 2003
128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended
ProSoft Technology, Inc.
January 2, 2008
Phantom Network Protocol Master Communication Module
System Requirements.............................................................. 9
Package Contents.................................................................. 10
Setting Jumpers ..................................................................... 11
Install the Module in the Rack ................................................ 12
Connect your PC to the Processor......................................... 13
Download the Sample Program to the Processor .................. 14
Connect your PC to the Module ............................................. 17
