Misc. Status - ProSoft Technology MVI56-PNPM User Manual

Reference

5.6.6 Misc. Status

Register
6670
6671 to 6672
6673 to 6674
6675 to 6676
6677 to 6678
6679
6680
6681
6682
6683
6684
6685
6686
6687
6688
6689
6690
6691
6692
6693
6694
6695
ProSoft Technology, Inc.
January 2, 2008
Phantom Network Protocol Master Communication Module
Content
Program Scan Count
Product Code
Product Version
Operating System
Run Number
Port 1 Command List
Requests
Port 1 Command List
Response
Port 1 Command List
Errors
Port 1 Requests
Port 1 Responses
Port 1 Errors Sent
Port 1 Errors Received
Port 2 Command List
Requests
Port 2 Command List
Response
Port 2 Command List
Errors
Port 2 Requests
Port 2 Responses
Port 2 Errors Sent
Port 2 Errors Received
Read Block Count
Write Block Count
Parse Block Count
MVI56-PNPM ♦ ControlLogix Platform
Description
This value is incremented each time a complete
program cycle occurs in the module.
These two registers contain the product code of
"PNP".
These two registers contain the product version for
the current running software.
These two registers contain the month and year
values for the program operating system.
These two registers contain the run number value
for the currently running software.
This field contains the number of requests made
from this port to slave devices on the network.
This field contains the number of slave response
messages received on the port.
This field contains the number of command errors
processed on the port. These errors could be due to
a bad response or command.
This field contains the total number of messages
sent out of the port.
This field contains the total number of messages
received on the port.
This field contains the total number of message
errors sent out of the port.
This field contains the total number of message
errors received on the port.
This field contains the number of requests made
from this port to slave devices on the network.
This field contains the number of slave response
messages received on the port.
This field contains the number of command errors
processed on the port. These errors could be due to
a bad response or command.
This field contains the total number of messages
sent out the port.
This field contains the total number of messages
received on the port.
This field contains the total number of message
errors sent out the port.
This field contains the total number of message
errors received on the port.
This field contains the total number of read blocks
transferred from the module to the processor.
This field contains the total number of write blocks
transferred from the module to the processor.
This field contains the total number of blocks
successfully parsed that were received from the
processor.
Page 75 of 91
