Register
6696
6697
6698
6699
6700
6701
6702
6703 to 6749
6750
6751
6752
6753 to 6759
6760
6761
6762
6763 to 6799

5.6.7 Command Control

Register
6800
6801
-
6999
Page 76 of 91
Content
Command Event Block
Count
Command Block Count
Error Block Count
Port 1 Current Error
Port 1 Last Error
Port 2 Current Error
Port 2 Last Error
Spare
Port 1 Use Guard Band
Port 1 Guard Band Time
Port 1 Fcn 99 Offset
Spare
Port 2 Use Guard Band
Port 2 Guard Band Time
Port 2 Fcn 99 Offset
Spare
Content
Command Code
Command Data
-
Command Data
Description
This field contains the total number of command
event blocks received from the processor.
This field contains the total number of command
blocks received from the processor.
This field contains the total number of block errors
recognized by the module.
For a slave port, this field contains the value of the
current error code returned. For a master port, this
field contains the index of the currently executing
command.
For a slave port, this field contains the value of the
last error code returned. For a master port, this field
contains the index of the command with the error.
For a slave port, this field contains the value of the
current error code returned. For a master port, this
field contains the index of the currently executing
command.
For a slave port, this field contains the value of the
last error code returned. For a master port, this field
contains the index of the command with an error.
Use packet gap timeout for messages (Yes or No).
Use only in multi-drop applications.
A value of 0 uses the default baud rate or you can
set a timeout value in milliseconds.
Internal DB offset to Function 99 counter.
Use packet gap timeout for messages (Yes or No).
Use only in multi-drop applications.
A value of 0 uses the default baud rate or you can
set a timeout value in milliseconds.
Internal DB offset to Function 99 counter.
Description
Enter one of the valid control command codes in
this register to control the module (9997, 9998, or
9999).
Not Used
-
Not Used
Reference
