MVI56-PNPM ♦ ControlLogix Platform
Phantom Network Protocol Master Communication Module
3

Ladder Logic

Ladder logic is required for application of the MVI56-PNPM module. Tasks that
must be handled by the ladder logic are module data transfer, special block
handling and status data receipt. Additionally, a power-up handler may be
needed to handle the initialization of the module's data and to clear any
processor fault conditions.
The sample ladder logic, on the ProSoft Solutions CD-ROM, is extensively
commented, to provide information on the purpose and function of each rung. For
most applications, the sample ladder will work without modification.
Page 30 of 91
Ladder Logic
ProSoft Technology, Inc.
January 2, 2008
