Port 2 Setup; Port 1 Commands; Port 2 Commands - ProSoft Technology MVI56-PNPM User Manual

MVI56-PNPM ♦ ControlLogix Platform
Phantom Network Protocol Master Communication Module

5.6.3 Port 2 Setup

Register
5032
5035
5033
5034
5036
5037 to 5039

5.6.4 Port 1 Commands

Register
5050 to 5077
5058 to 5065
-
5842 to 5849

5.6.5 Port 2 Commands

Register
5860 to 5867
5868 to 5875
-
6652 to 6659
Page 74 of 91
Content Description
Command Count This parameter specifies the number of commands
to be processed by the master port.
Minimum Command This parameter specifies the number of milliseconds
Delay to wait between issuing each command. This delay
value is not applied to retries.
Response Timeout This parameter represents the message response
timeout period in 1-millisecond increments. This is
the time that a port configured as a master will wait
before re-transmitting a command if no response is
received from the addressed slave. The value is set
depending upon the communication network used
and the expected response time of the slowest
device on the network.
Retry Count This parameter specifies the number of times a
command will be retried if it fails. If the master port
does not receive a response after the last retry, the
slave devices communication will be suspended on
the port for Error Delay Counter scans.
Error Delay Counter This parameter specifies the number of polls to skip
on the slave before trying to re-establish
communications. After the slave fails to respond,
the master will skip commands to be sent to the
slave the number of times entered in this parameter.
Spare
Content Description
Command #1 This set of registers contains the parameters for the
first command in the master command list. The
structure of this data area is as described in the
data object section of the documentation.
Command #2 Command #2 data set
- -
Command #100 Command #100 data set
Content Description
This set of registers contains the parameters for the
Command #1
first command in the master command list. The
structure of this data area is as described in the
data object section of the documentation.
Command #2 Command #2 data set
- -
Command #100 Command #100 data set
Reference
ProSoft Technology, Inc.
January 2, 2008
