LK15
LK14
LK13
rw
rw
rw
Bits
Fields
31:17
Reserved
16
LKK
15:0
LKy
7.5.8.

Event control register (AFIO_EC)

Address offset: 0x00
Reset value: 0x0000 0000
This register has to be accessed by word (32-bit).
31
30
29
15
14
13
Bits
Fields
31:8
Reserved
7
EOE
6:4
PORT[2:0]
LK12
LK11
LK10
LK9
rw
rw
rw
rw
Descriptions
Must be kept at reset value
Lock sequence key
It can only be setted using the Lock Key Writing Sequence. And can always be read.
0: GPIO_LOCK register is not locked and the port configuration is not locked.
1: GPIO_LOCK register is locked until an MCU reset..
LOCK key configuration sequence
Write 1→Write 0→Write 1→ Read 0→ Read 1
Note: The value of LK[15:0] must hold during the LOCK Key Writing sequence.
Port Lock bit y(y=0..15)
These bits are set and cleared by software
0: The corresponding bit port configuration is not locked
1: The corresponding bit port configuration is locked when LKK bit is "1"
28
27
26
25
12
11
10
9
Reserved
Descriptions
Must be kept at reset value
Event output enable
Set and cleared by software.When set the EVENTOUT RISC-V output is connected
to the I/O selected by the PORT[2:0] and PIN[3:0] bits
Event output port selection
Set and cleared by software.Select the port used to output the RISC-V EVENTOUT
signal.
000: Select PORT A
001: Select PORT B
010: Select PORT C
GD32VF103 User Manual
LK8
LK7
LK6
LK5
rw
rw
rw
rw
24
23
22
21
Reserved
8
7
6
5
EOE
PORT[2:0]
rw
rw
LK4
LK3
LK2
LK1
rw
rw
rw
rw
20
19
18
17
4
3
2
1
PIN[3:0]
rw
LK0
rw
16
0
119
