AN117 Precautions for the use of USBHS of GD32H7xx series Foreword This document is intended for GD32H7xx MCU and introduces precautions during USBHS development and use, including clock configuration, GPIO configuration, PHY configuration, power supply configuration, and other software configurations. For the hardware part of USBHS, please refer to Manual of Hardware Development of AN109 GD32H7xx Seriess.
AN117 Precautions for the use of USBHS of GD32H7xx series Precautions for the use of UBSHS UBSHS clock configuration 2.1. Peripheral module clock 2.1.1. USBHS peripheral clock tree is as shown in tree. Figure 2-1. USBHS clock Figure 2-1. USBHS clock tree EMBPHY_HS USB HS PHY clock 24Mhz to 60Mhz CK_USBHS_ULPI...
AN117 Precautions for the use of USBHS of GD32H7xx series Then, the 480M clock can be used by USBHS module through USBHSxDV frequency division. Figure 2-2. Internal PHY clock tree GPIO configuration of USBHS 2.2. When enabling ADP function, it is required to configure VBUS pins (PA9 (USBHS0), PB12 (USBHS1)) in analog mode.
AN117 Precautions for the use of USBHS of GD32H7xx series Other precautions 2.5. When using internal PHY, DP/DM pins of the data lines are not required to be connected with the matching resistor in series. When using external ULPI PHY, PHY is allowed to provide 60M clock signal to MCU, but MCU is not allowed to output 60M clock signal to PHY.
AN117 Precautions for the use of USBHS of GD32H7xx series Revision history Table 3-1. Revision history Revision No. Description Date Initial release Apr. 11, 2023...
