XPA200-7984-I-OPT1, X-Band SSPA
3.3.2.2 Entry Mode
Mode:
is Local.
3.3.2.3 Fault Recovery:
default is Auto.
3.3.3 Monitor Status Menu
Monitors and displays the status of:
! All SSPA power supplies.
! SSPA internal temperature.
! RF output power level.
! RF FET currents (Q1 through Q19).
3.3.4 Current Faults Menu
Displays the status of the current fault conditions.
LCD display will indicate "FT" when a fault condition exists.
The display will indicate "OK" when a fault has not occurred.
3.3.4.1 Power Faults
Displays the DC voltage power supply faults.
voltages displayed are:
!
!
!
!
!
!
XPA200-7984-I-OPT1, Rev.2
The entry mode is Local or Remote.
Fault Recovery is Manual or Auto.
+12 VDC.
-12 VDC.
VCC.
-5 VDC.
+28 VDC
+10 VDC, PS1 and PS2
System Operation
The default
The
The
The DC
3-11
