XPA200-7984-I-OPT1, X-Band SSPA
UP
------
-- CONFIGURATION MENU
ATTENUATION - =-10.00 -dB--
AMPLIFIER=-ON--MUTE=-OFF
(See Para. 3.3.2.1)
- ENTRY MODE -= REMOTE -
------------------------
(See Para. 3.3.2.2)
FAULT RECOVERY:MANUAL
---------------------
(See Para. 3.3.2.3)
Figure 3-2.
XPA200-7984-I-OPT1, Rev.2
(See Para. 3.3.2)
SELECT ------
DOWN
ENTER
Configuration Menu Commands.
LEGEND
UP
KEY-PAD
DOWN
---------------------
DISPLAY
---------------------
System Operation
ENTER
RIGHT
LEFT
CLR
3-4
