Comtech EF Data XPA-200 Installation And Operation Manual page 38

XPA200-7984-I-OPT1, X-Band SSPA
Item
Key-Pad;
ENT key
Key-Pad;
CLR key
Key-Pad;
Right Arrow key
Key-Pad;
Left Arrow key
Key-Pad;
Up Arrow key
Key-Pad;
Down Arrow key
LCD Display
STATUS Indicator,
Green
STATUS Indicator,
yellow
STATUS Indicator,
yellow
STATUS Indicator,
yellow
STATUS Indicator,
Red
STATUS Indicator,
Red
INPUT SAMPLE
OUTPUT SAMPLE
XPA200-7984-I-OPT1, Rev.2
Table 3-1. Operating Functions - Front Panel
Functional Description
Enters commands into the
converter.
Clears commands and data selected
and not entered.
Selects functions and the menu
operating data.
Selects functions and the menu
operating data.
Selects the operating menu and
data values.
Selects the operating menu and
data values.
Displays commands and data entered
into the key-pad.
Prime power is applied when the
light is on.
Transmit function operating when
the light is on.
In Remote Control Mode when the
light is on.
Operating on-line to receive
data when the light is on.
Fault condition exists when the
light is on.
Faults stored and logged
when the light is on.
Type N connector test point
to sample RF input.
Type N connector test point to
sample RF output.
System Operation
Reference
Designation
ENT
CLR
Right Arrow
Left Arrow
Up Arrow
Down Arrow
POWER ON
TRANSMIT ON
REMOTE
ON LINE
FAULT
STORED
FAULT
SAMPLE INPUT
SAMPLE OUTPUT
3-2
