XPA200-7984-I-OPT1, X-Band SSPA
exhausted out the rear panel.
output airflow paths are not obstructed or restricted.
minimize the amplifier operating temperature, and provide years of
reliable operation.
If the SSPA is to be mounted on slides, the slides must be the
COMTECH rack slides provided with the SSPA.
sides of the SSPA chassis with the mounting hardware provided.
Then, install the slide rails in the rack cabinet enclosure.
Secure the SSPA to the rack cabinet with four screws inserted
through the SSPA front panel slotted holes.
2.2.2 Combined/Redundant Amplifier Installation and Cabling
For the complete combined/redundant amplifier system, it is
most common to install the Mitec 2723B combiner in the top position
of the rack, followed by SSPA B, with SSPA A in the bottom position.
(See the outline drawing at the end of this section.)
Connect the Comtech supplied inter-unit control cable,
CA/8981, between the Mitec Combiner ports P1,P2,P3 and to each J5 of
SSPA A and SSPA B as indicated by the labels on the cable. (Note
that this cable is setup for the bottom SSPA be SSPA A.)
Attach the supplied waveguide termination to the load port of
the Mitec 2723B such that the termination resides above the unit.
(See outline drawing.)
Attach user supplied coaxial cables and waveguide between the
Mitec 2723B and each XPA200.
manual. A waveguide pressure window has also been supplied and can
be attached according to customer preference.
(Note that CA/8981 has been constructed for SSPA A to be in the
bottom position.
connected accordingly.
modify either CA/8981 or the coaxial cables and waveguides.)
Before applying AC power to the units, make sure the waveguide
output of the amplifiers and the antenna and load ports of the
combiner are properly terminated.
equipment damage and excessive RF radiation levels.
Attach power cords to the units. Two standard power cords are
supplied with the Mitec 2723B.
mating connector to enable the user to fabricate a power cord.
sections 1.4 and 1.11.4.
XPA200-7984-I-OPT1, Rev.2
Locate the unit so the input and
Refer to Figure 2.3 of the Mitec
The coaxial cables and waveguides should be
In case of conflict, it will be necessary to
CAUTION!
Each XPA200 is supplied with a
Mount the slides on the
Failure to do so could lead to
Installation
This will
See
2-2
