1.9 Front Panel Display
The front panel display is a two line by twenty-four
character, LCD display.
operating mode, is shown on the display when the operator enters
a command into the key-pad on the front panel.
1.10 Front Panel Test Point Samples
Two test point connections are located on the front panel
for monitoring the RF input and the RF output.
connector is provided for the RF sample test points.
1.11 Rear Panel Connections
The following is a list of the connectors on the rear panel:
! Connector J1: SSPA RF Input (RF in).
! Connector J2: SSPA RF Output (RF output).
! Connector J3: AC Prime Power Input (AC in).
! Connector J4: Cust. Discrete Control (Discrete Control).
! Connector J5: Combiner Interface.
! Connector J6: COM1 Port (RS-232C/RS-485) (COM1).
! AC Power On / Off Switch.
