CHAPTER 3 PROGRAMMING PATTERNS
■ 5. Inputting an end code
Once you have finished creating the program, edit the end code that controls the sewing machine operation.
The following six end codes from 111 to 116 are available, each of which carries out machine operations as shown in the table below.
When creating programs, an end point (normal) is set at the sewing end point.
111 Normal
112
Fixes the sewing speed at 1200 sti/min or lower
113 Carrying out no thread wiping
114
Fixes the sewing speed at 1200 sti/min or lower and no thread wiping is carried out
115 Carrying out no thread trimming
116
Fixes the sewing speed at 1500 sti/min or lower
1. Touch .
2. Touch .
3. Touch the end code that you would like to set, and then change the code.
