7. How to programme the frequency converter
Q3-30 Feedback Settings
1-00 Configuration Mode
20-12 Reference/Feedb.Unit
3-02 Minimum Reference
3-03 Maximum Reference
6-20 Terminal 54 Low Voltage
6-21 Terminal 54 High Voltage
6-24 Terminal 54 Low Ref/Feedb Value
6-25 Terminal 54 High Ref/Feedb Value
6-00 Live Zero Timeout Time
6-01 Live Zero Timeout Function
7
64
Q3-3 Closed Loop Settings
Q3-31 PID Settings
20-81 PID Normal/Inverse Control
20-82 PID Start Speed [RPM]
20-21 Setpoint 1
20-93 PID Proportional Gain
20-94 PID Integral Time
®
