7. How to programme the frequency converter
6-52 Terminal 42 Output Max Scale
Range:
100%
7
20-12 Reference/Feedback Unit
Option:
[0]
[1]
[5]
[10]
[11]
[12]
[20]
78
* [0.00 – 200%]
None
*
%
PPM
1/min
RPM
Pulse/s
l/s
MG.20.M2.02 - VLT
Function:
Scale the maximum output of the selected analog signal at ter-
minal 42. Set the value to the maximum value of the current
signal output. Scale the output to give a current lower than 20
mA at full scale; or 20 mA at an output below 100% of the
maximum signal value. If 20 mA is the desired output current
at a value between 0 - 100% of the full-scale output, pro-
gramme the percentage value in the parameter, i.e. 50% = 20
mA. If a current between 4 and 20 mA is desired at maximum
output (100%), calculate the percentage value as follows:
m A desired maximum current
20 /
20 m A
i e m A
. . 10 : × 100 % = 200 %
m A
10
