VLT AQUA Drive
Operating Instructions
0-21 Display Line 1.2 Small
Option:
[1662]
0-22 Display Line 1.3 Small
Option:
[1614]
0-23 Display Line 2 Large
Option:
[1615]
0-24 Display Line 3 Large
Option:
[1652]
0-37 Display Text 1
Option:
0-38 Display Text 2
Option:
Function:
Select a variable for display in line 1, middle position.
* Analog input 53 The options are the same as those listed for par. 0-20
Line 1.1 Small
Function:
Select a variable for display in line 1, right position.
* Motor Current The options are the same as those listed for par. 0-20
Line 1.1 Small
Function:
Select a variable for display in line 2. The options are the same
as those listed for par. 0-20
* Frequency
Function:
*
Feedback [Unit] Select a variable for display in line 2. The options are the same
as those listed for par. 0-20
Function:
In this parameter it is possible to write an individual text string
for display in the LCP or to be read via serial communication. If
to be displayed permanently select Display Text 1 in par. 0-20,
0-21, 0-22, 0-23 or 0-24,
tons on the LCP to change a character. Use the ◀ and ▶ buttons
to move the cursor. When a character is highlighted by the cur-
sor, it can be changed. Use the ▲ or ▼ buttons on the LCP to
change a character. A character can be inserted by placing the
cursor between two characters and pressing ▲ or ▼.
Function:
In this parameter it is possible to write an individual text string
for display in the LCP or to be read via serial communication. If
to be displayed permanently select Display Text 2 in par. 0-20,
0-21, 0-22, 0-23 or 0-24,
tons on the LCP to change a character. Use the ◀ and ▶ buttons
to move the cursor. When a character is highlighted by the cur-
®
MG.20.M2.02 - VLT is a registered Danfoss trademark
7. How to programme the frequency converter
.
.
Display Line 1.1 Small
Display Line 1.1 Small
Display Line XXX . Use the ▲ or ▼ but-
. Use the ▲ or ▼ but-
Display Line XXX
Display
Display
7
.
.
69
