VLT AQUA Drive
Operating Instructions
The MCT 10 Set-up Software will be
useful for:
•
•
•
MCT 10 Set-up Software supports Profibus DP-V1 via a Master class 2 connection. It makes it
possible to on line read/write parameters on-line in a frequency converter via the Profibus network.
This will eliminate the need for an extra communication network.
Save Frequency Converter Settings:
1.
2.
3.
4.
All parameters are now stored in the PC.
Load Frequency Converter Settings:
1.
2.
3.
4.
5.
All parameter settings are now transferred to the frequency converter.
A separate manual for MCT 10 Set-up Software is available: MG.10.R2.02.
The MCT 10 Set-up Software Modules
The following modules are included in the software package:
Ordering number:
Please order the CD containing MCT 10 Set-up Software using code number 130B1000.
MCT 10 can also be downloaded from the Danfoss Internet: WWW.DANFOSS.COM, Business Area:
Motion Controls.
Planning a communication network
off-line. MCT 10 contains a complete
frequency converter database
Commissioning frequency convert-
ers on line
Saving settings for all frequency con-
verters
Connect a PC to the unit via USB com port. (Note: Use a PC, which is isolated from the
mains, in conjunction with the USB port. Failure to do so may damage equipment.)
Open MCT 10 Set-up Software
Choose "Read from drive"
Choose "Save as"
Connect a PC to the frequency converter via USB com port
Open MCT 10 Set-up software
Choose "Open"– stored files will be shown
Open the appropriate file
Choose "Write to drive"
MCT 10 Set-up Software
Setting parameters
Copy to and from frequency converters
Documentation and print out of parameter settings incl. diagrams
Ext. User Interface
Preventive Maintenance Schedule
Clock settings
Timed Action Programming
Smart Logic Controller Set-up
Casade Control Config. Tool
®
MG.20.M2.02 - VLT is a registered Danfoss trademark
6. How to operate the frequency converter
• Replacing a frequency converter in a
network
• Simple and accurate documentation
of frequency converter settings after
commissioning.
• Expanding an existing network
• Future developed frequency con-
verters will be supported
6
