AMI Codes-II TC
Program List and Explanations
4.3.1
Interval 1 s
Time 25 min
4.3.2
4.4 Display
4.4.1
4.4.1.1
4.4.1.2
4.4.1.3
4.4.2

5 Installation

5.1 Sensors
5.1.1
5.1.2
A-96.250.631 / 280219
Log Interval: Select a convenient log interval. Consult the table
below to estimate the max logging time. When the login buffer is
full, the oldest data record is erased to make room for the newest
one. (circular buffer)
5 s 1 min
2 h 25 h
Clear Logger: If confirmed with yes, the complete logger data is
deleted. A new data series is started.
Process values are displayed on two screens. Toggle screens with
the [ ] key. Each screen displays max. 3 process values.
Screen 1
Row 1
Row 2
Row 3
Possible settings for all rows are:
 None
 Total chlorine 1
 Total chlorine 2
 Calc. dichloramine
 pH
Screen 2
Same as screen 1.
Dimension: The measuring value can be displayed as ppm or mg/l
Ref. Verification: Set absorbance value of verification kit according
to label.
Range: 0.200–0.600
5 min 10 min
5 d 10 d
30 min 1 h
31 d 62 d
Event
Driven
85
