AMI Codes-II TC
Troubleshooting
Error
E010 Sample Flow low
E011 Temp. shorted
E012 Temp. disconnected
E013 Case Temp. high
E014 Case Temp. low
E015 Valve 1 defective
E016 DIS invalid
E017 Control Timeout
E018 Reagent Pump
E019 Photometer not con-
nected
A-96.250.631 / 280219
Description Corrective action
– check Inlet pressure
– readjust sample flow
– clean instrument, see
protective Filter, p. 54
– check program value
– check wiring of temperature sensor, see
Connection Diagram, p. 28
– check temperature sensor
– check wiring of temperature sensor, see
Connection Diagram, p. 28
– check temperature sensor
– check case/environment temperature
– check program value
– check case/environment temperature
– check program value
– check Valve 1, see
solenoid valve, p. 62
– This error appears after start-up and will
disappear after the first valid
measurement is finished.
– check control device or programming in
Installation, Relay contact, Relay 1 and
2 5.3.2/3, p. 93
– shut off power
– check wiring, see
p. 28
– shut off power
– check wiring, see
p. 28
Cleaning the
5.3.1.3.35, p. 92
Cleaning the
Connection Diagram,
Connection Diagram,
