AMI Codes-II TC
Program List and Explanations
5.4.3
5.4.4
5.4.5
5.4.6
5.5 Interface
5.5.1
5.5.20
5.5.30
5.5.40
5.5.1
5.5.21
5.5.31
5.5.41
5.5.1
5.5.1
A-96.250.631 / 280219
Load Firmware: Firmware updates should be done by instructed
service personnel only.
Password: Select a password different from 0000 to prevent unau-
thorized access to the menus "Messages", "Maintenance", "Opera-
tion" and "Installation".
Each menu may be protected by a different password.
If you forgot the passwords, contact the closest SWAN representa-
tive.
Sample ID: Identify the process value with any meaning full text,
such as KKS number.
Line Break Detection: Define if message E028 should be issued in
case of a line break on signal output 1 or 2.
Choose between <Yes> or <No>.
Select one of the following communication protocols. Depending on
your selection, different parameters must be defined.
Protocol: Profibus
Device address:
ID-Nr.:
Local operation:
Protocol: Modbus RTU
Device address:
Baud Rate:
Parity:
Protocol: USB-Stick:
Only visible if an USB interface is installed. No further settings are
possible.
Protocol: HART
Device address:
Range: 0–126
Range: Analyzer; Manufacturer; Multivariable
Range: Enabled, Disabled
Range: 0–126
Range: 1200–115 200 Baud
Range: none, even, odd
Range: 0–63
99
