AMI Codes-II TC

Instrument Setup

4.
4.1.
4.2.
36
Instrument Setup
After installation according to checklist proceed as follows:

Prepare Reagents

1 Prepare reagents. See
2 Insert the suction lances into the canisters.

Peristaltic Pump

The instrument is delivered with opened occlusion frames.
1 Activate the peristaltic pump tubes by closing the occlusion
frames [B].
Refill or replace Reagents, p.
A Turn to lock
B Occlusion frame
A
C Rotor
D Pump tube
B
C
D
46.
A-96.250.631 / 280219
