Installation

Installation Check List

Instrument's specification must conform to your power ratings. Do
not switch on power until all external devices are connected.
The transmitter is intended for panel mounting. The dimensions
are shown under
Connect all external devices, see
Connect the power cord, but do not switch on power until all exter-
nal devices are connected.
The Swansensor Oxytrace G is delivered with prefilled electrolyte
chamber. A transport protection cap filled with water keeps the
sensor wet during transport and storage. Before installation,
remove the transport protection cap and clean the sensor sur-
faces with water. Afterwards install the oxygen sensor and con-
nect the cable.
See Install the Swansensor Oxytrace G, p.
Switch on power.
First, the analyzer performs a self test, displays the firmware ver-
sion and then starts normal operation
Leave the sensor at the air. The sensor has to run in for at least
30 min, better 1 h. During this time it has to be at air with a dry and
clean membrane and has to be connected to the powered instru-
ment. Calibrate the sensor after this time, see
and mount it into the flow cell afterwards.
Open the flow regulating valve and wait until the flow cell is filled
and the sample flows into the drain.
Program all parameters for external devices (interface, etc.). Set
all parameters for instrument operation (limits, alarms).
Dimensions of the AMU Transmitter, p.
Electrical Connection, p.
15.
17.
16.
Calibration, p. 32.
