Cleaning The Photometer - Swan Analytical Instruments AMI Codes-II TC Operator's Manual

AMI Codes-II TC
Maintenance
6.7.
Material
Procedure
A-96.250.631 / 280219

Cleaning the Photometer

Clean the photometer after indication by alarm (E020, FOME dirty).
Switch off the instrument according to instructions in
tion for Maintenance, p.
Small brush.
B
C
1 Close the flow regulating valve [A].
2 Wait until the sample flow through the photometer has stopped.
3 Unscrew the cover [B] from the photometer [C].
D
C
4 Clean the Photometer with a small brush [D].
5 Screw the cover to the photometer.
6 Open the flow regulating valve.
45.
A
B
C
A
D
Stop of Opera-
Flow regulating valve
Photometer cover
Photometer
Brush
55
