AMI Codes-II TC
Program List and Explanations
5.3.2.24
5.3.2.24
5.3.2.340
5.3.2.44
5.3.2.54
5.3.2.6
5.3.2.7
5.3.2.24
5.3.2.341
5.3.2.44
5.3.2.54
5.3.2.6
96
Mode: Operating mode (interval, daily, weekly)
Interval
Interval: The interval can be programmed within a range
of 1–1'440 min.
Run Time: Enter the time the relay stays active.
Range: 5–32'400 sec.
Delay: during run time plus the delay time the signal and control
outputs are held in the operating mode programmed below.
Range: 0–6'000 sec.
Signal Outputs: Select operating mode of the signal output:
Cont.: Signal outputs continue to issue the measured value.
Hold: Signal outputs hold the last valid measured value.
Measurement is interrupted. Errors, except fatal errors,
are not issued.
Off: Signal outputs are switched off (set to 0 or 4 mA).
Errors, except fatal errors, are not issued.
Output/Control: Select operating mode of the controller output:
Cont.: Controller continues normally.
Hold: Controller continues based on the last valid value.
Off: Controller is switched off.
daily
The relay contact can be activated daily, at any time of a day.
Start time: to set the start time proceed as follows:
1 Press [Enter], to set the hours.
2 Set the hour with the [
3 Press [Enter], to set the minutes.
4 Set the minutes with the [
5 Press [Enter], to set the seconds.
6 Set the seconds with the [
Range: 00:00:00–23:59:59
Run Time: see Interval
Delay: see Interval
Signal Outputs: see Interval
] or [ ] keys.
] or [ ] keys.
] or [ ] keys.
A-96.250.631 / 280219
