AMI Codes-II TC
Installation
A-96.250.631 / 280219
Level
To install the constant head tube proceed as follows:
1 Unpack the constant head tube [C].
2 Push the constant head tube into the flow cell block [E].
3 Put the constant head cover [A] onto the constant head tube.
4 Check if the overflow tube [B] is aligned with the upper level
mark.
A Constant head cover
A
B Overflow tube
C Constant head tube
D Gasket
E Flow cell block
B
C
D
E
21
