Coil
Description
number
Frequency converter control word
1–16
(see Table 7.16).
Frequency converter speed or
17–32 setpoint reference range 0x0–
0xFFFF (-200% ... ~200%).
Frequency converter status word
33–48
(see Table 7.17).
Open-loop mode: Frequency
converter output frequency.
49–64
Closed-loop mode: Frequency
converter feedback signal.
Parameter write control (master to
slave).
0 = Parameter changes are written
to the RAM of the frequency
65
converter.
1 = Parameter changes are written
to the RAM and EEPROM of the
frequency converter.
66–65536 Reserved.
Table 7.15 Coil Register
Coil 0
01 Preset reference lsb
02 Preset reference msb
03 DC brake
04 Coast stop
05 Quick stop
06 Freeze frequency
07 Ramp stop
08 No reset
09 No jog
10 Ramp 1
11 Data not valid
12 Relay 1 off
13 Relay 2 off
14 Set up lsb
15 –
16 No reversing
Table 7.16 Frequency Converter Control Word (FC Profile)
MG18C702
Design Guide
Signal
direction
Master to slave
Master to slave
Slave to master
Slave to master
Master to slave
–
1
No DC brake
No coast stop
No quick stop
No freeze frequency
Start
Reset
Jog
Ramp 2
Data valid
Relay 1 on
Relay 2 on
Reversing
Danfoss A/S © 04/2016 All rights reserved.
Coil 0
33 Control not ready
Frequency converter not
34
ready
35 Coast stop
36 No alarm
37 Not used
38 Not used
39 Not used
40 No warning
41 Not at reference
42 Hand mode
43 Out of frequency range
44 Stopped
45 Not used
46 No voltage warning
47 Not in current limit
48 Thermal level is OK
Table 7.17 Frequency Converter Status Word (FC Profile)
1
Control ready
Frequency converter ready
Safety closed
Alarm
Not used
Not used
Not used
Warning
At reference
Auto mode
In frequency range
Running
Not used
Voltage exceeds
Current limit
Thermal level exceeds
