Danfoss VLT HVAC Basic Drive FC 101 Design Manual page 61

Installation
Enclosure size I4
1 RS485
2 Mains
3 Ground
4 Cable clamps
5 Motor
6 UDC
7 Relays
8 I/O
Illustration 5.10 Enclosure Size I4
IP54, 380–480 V, 0.75–4.0 kW (1–5 hp)
Illustration 5.11 IP54 Enclosure Sizes I2, I3, I4
MG18C702
Design Guide
Enclosure size I6
Illustration 5.12 Mains Connection for Enclosure Size I6
IP54, 380–480 V, 22–37 kW (30–50 hp)
Illustration 5.13 Motor Connection for Enclosure Size I6
IP54, 380–480 V, 22–37 kW (30–50 hp)
Danfoss A/S © 04/2016 All rights reserved.
5 5
59
