General Specifications
400 V 55 kW (74 hp)
400 V 75 kW (100 hp)
400 V 90 kW (120 hp)
600 V 7.5 kW (10 hp)
Table 8.12 dU/Dt Data
8 8
118
®
VLT HVAC Basic Drive FC 101
Cable length [m (ft)] AC line voltage [V]
10 (33)
10 (33)
10 (33)
5 (16)
50 (164)
5 (16)
50 (164)
Danfoss A/S © 04/2016 All rights reserved.
Rise time [μsec]
400 0.46
480 0.468
400 0.502
480 0.52
500 0.51
400 0.402
400 0.408
400 0.424
525 0.192
525 0.356
600 0.184
600 0.42
V [kV] dU/dt [kV/μsec]
peak
1.12 1.948
1.3 2.222
1.048 1.673
1.212 1.869
1.272 1.992
1.108 2.155
1.288 2.529
1.368 2.585
0.972 4.083
1.32 2.949
1.06 4.609
1.49 2.976
MG18C702
