Ip21/Nema Type 1 Enclosure Kit - Danfoss VLT HVAC Basic Drive FC 101 Design Manual

Selection and Ordering
Step 4
Connect cable to frequency converter.
4 4
Illustration 4.5 Connect Cable
NOTICE
Use the provided thread-cutting screws to fasten the
connector to the frequency converter. The tightening
torque is 1.3 Nm (11.5 in-lb).

4.2.3 IP21/NEMA Type 1 Enclosure Kit

IP21/NEMA Type 1 is an optional enclosure element
available for IP20 units.
If the enclosure kit is used, an IP20 unit is upgraded to
comply with enclosure IP21/NEMA Type 1.
48
®
VLT HVAC Basic Drive FC 101
Illustration 4.6 H1–H5 (See Data in Table 4.4)
Illustration 4.7 Dimensions (See Data in Table 4.4)
Danfoss A/S © 04/2016 All rights reserved.
C
On
Warn.
Alarm
B
MG18C702
