rS422 S
eriaL
Two serial control services are available on C10 HD systems:
1. Router name transfer using the Probel PB08 protocol.
2. Remote control automation using the Sony ELC or Ross Overdrive protocols. An license upgrade is required to
activate the Automation feature.
i Refer to Appendix G of the C10 Operators Manual for further details of the automation feature.
It will be necessary to install appropriate cabling between the console and the remote equipment.
Two serial ports are located on the console main connector panel. Note that the console includes internal switching so
that the serial ports will automatically become redundant on systems that feature dual Blackrock processors.
Either serial service can be assigned to the serial connectors. The port allocations are stored in system text files which
can entered via the touchscreen terminal.
Serial Port File allocation
Physical Port
Console Serial Port 1
Console Serial Port 2
t
ouchScreen
A duplicate of the centre section touch-screen image is available on an XGA connector beneath the console. The
connector is located on the additional connector panel; pinout follows standard HD-15 VGA.
Please note that the image output is in portrait orientation, not landscape, so an external monitor will need to be able
to rotate by 90°.
Image resolution is 1024 x 768 @ 60Hz,
C10 HD Installation Manual
P – a
ortS utomation
Software Identification
12
13
v o
iDeo utPut
/r D
outer ata
Section 3: Installation
Serial Ports
| Page 3-23
