SeRVice inFoRMAtion
i
ntRodUction
The following pages provide detailed guides to assist during the removal of console sub-assemblies as may be required for
servicing or maintenance.
The following tools are supplied with the console trim kit:
2mm hex driver
Posidrive no.1 screwdriver
Module puller
6mm Hex key
In addition to the above a small flat-bladed screwdriver will be required to remove the locking screws on D-type
connectors.
S
i
AFety
nFoRMAtion
Always use the software 'Shutdown' process before switching off power to the console.
Using the touchscreen menus: press 'Studio' (spanner icon) –> 'System' (gear wheels icon) –> 'Shutdown' (Console with cross
icon) then select the 'Shutdown' button from the four options. Wait until the screens become black before switching off the
console power.
Always switch off the mains power to both inputs AND remove both of the input power IEC connectors
before removing any panels or trim.
Component surfaces inside may be hot immediately after switching off.
There may be sharp edges exposed inside the console frame.
To help protect panels from becoming scratched after removal, have a soft cloth or sheet of antistatic foam to hand
before removing them from the frame.
A plastic cup is a useful place to store fixing screws after their removal; it prevents them from falling inside the
frame and makes them easy to find during reassembly.
C10 HD Installation Manual
Used to remove the fixing screws for the fader and control tiles.
Used for other M3 fixing screws.
Custom M4 screw used to lift the edges of the control tiles to aid removal.
Suitable for the leg fixing bolts.
Section 7: Service Information
Introduction
|
Page 7-iii
