Front Panel Menu; Front Panel Menu; Scribble; Settings - Solid State Logic C10 HD Installation Manual

F P
ront AneL
These options within the Maintenance pages allow a number of facilities to be configured that relate to the
operating surface of the console.
The submenus are: Scribble, Settings, ethernet FP Setup, and Fader reset.
S
criBBLe
This pop-up allows the electronic scribble strips (found above every fader) to be configured. The pop-up shows two
options:
The default channel name option allows you to enter a default name for the scribble strips when no user name has
been entered (the console will automatically add the appropriate fader number to the end of this). If you leave this box
blank, then the input name of the channel source will be copied directly to the scribble strip – ideal for channels fed from
a router as its name labels may then be dynamically imported to the channel TFT screen and the scribble display
simultaneously!
The Show Faders' dB option allows the momentary display of the fader gain in the scribble window when the fader is
adjusted.
S
ettingS
This pop-up includes three small faders which control the brightness of (from left to right) the console's screens, scribble
strip, and LEDs.
To adjust each fader, simply drag it on the Touchscreen.
To set the '2nd function' time delay for all press-and-hold functions (such as resetting the EQ section), touch the
Press & hold delay box, type a new time and press enter.
To switch the Centre Section softkeys between Banked and Unbanked modes, touch the box by the Banks of Soft
Keys label. The box is ticked when banks are active.
C10 HD Installation Manual
m
enu
Section 5: System Administration

Front Panel Menu

| Page 5-51
