Solid State Logic C10 HD Installation Manual page 186

A: Specifications
AppendiceS
A: S
peciFicAtionS
c10 hd console
Parameter
Height
Height adjustment
Width
Depth
Weight
Heat Dissipation
Voltage
Current
Power Factor
Fusing
Noise
Connectors
* CPU redundancy is not available on the 8-channel frame.
Page 6-iv | Section 6: Appendices
Condition
To top of meter trim
24 channel console
Additional 8 channel bay
Contoured side trims
8 channel
16 channel
24 channel
32 channel
40 channel
8 channel
16 channel
24 channel
32 channel
40 channel
Range
8ch max. over voltage range
16ch max. over voltage range
24ch max. over voltage range
32ch max. over voltage range
40ch max. over voltage range
No user-accessible fuses
Fanless
Power in Main/Backup
Network TCP/IP
MADI fibre
GPI input
GPI output
Headphone input
Talkback audio output
Value Unit
977 mm
-0 +10 mm
1146 mm
+285 mm
+60 mm
768 mm
35 kg
65 kg
83 kg
97 kg
113 kg
125* W
225 (275) W
250 (300) W
280 (330) W
315 (365) W
100 – 240 V
1.0 – 0.5 A
2.3 – 1.0 A
3.0 – 1.2 A
3.1 – 1.3 A
3.4 – 1.5 A
0.95
IEC 3-pin male 10A
RJ45 100 baseT
Duplex LC multimode (not APC)
25-way D-type male
25-way D-type female
XLR 3-way female
XLR 3-way male
Notes
Add or subtract
30mm each side
+ additional 15mm for heatsinks
Approximately, without legs
Approximately, including legs
" "
" "
" "
Worst case, single CPU
Single CPU (Redundant CPU)
" "
" "
" "
±10%, AC only
Approximately
C10 HD Installation Manual
